LiveScope™ LVS44 Transducer Pre Order DEPOSIT
LiveScope™ LVS44 Transducer Pre Order DEPOSIT
Regular price
$500.00
Regular price
$1,999.99
Sale price
$500.00
Unit price
per
Couldn't load pickup availability
$500 NON REFUNDABLE DEPOSIT
REMAINING BALANCE OF $1499.99 Upon Shipment.
OUR FARTHEST-REACHING, CLEAREST SONAR EVER
You’ve never seen live-scanning sonar of this clarity reach this far. LiveScope 2 offers increased resolution, integrated image stabilization and improved stitching, so you’ll clearly see fish and structure.
CLEAR IMAGERY WITH BETTER TARGET SEPARATION
NO BLACK BOX NEEDED, SO INSTALL IS EASY
SEE DETAILED IMAGERY AT CASTABLE RANGE AND BOTTOM TRACK OUT TO 250 FEET
SONAR AUTOMATICALLY TURNS OFF WHEN THE TRANSDUCER IS OUT OF THE WATER
WIDER ANGLES IN FORWARD, DOWN AND PERSPECTIVE MODES
General |
|
| Transducer beamwidth | Forward: 20° x 165° Down, Perspective: 20° x 180° |
|---|---|
| Transducer cable length | 5.5 m (18 ft) |
| Transducer number of pins | 7 |
| Dimension | 6.3” x 5.6” x 1.9” (16.0 x 14.2 x 4.8 cm) |
| Weight |
3.93 lbs (1.790 kg) |
| Temperature range | Operating: 0 C to 40 C |
Electrical Features |
|
| Power Input | 10-35 V |
|---|---|
| Power usage | 32 W max |
| Fuse | 7.5 A |
| Compass safe distance | 4" |
Sonar Features |
|
| Frequency | 600 kHz-1050 kHz |
|---|---|
| Transmit power | 392 W |
| Maximum depth | Down and Forward: 250’ |
| Sonar Type | Live |
| Target Separation @ 100' | 12.6" |
| Target separation @ 30' | 5.7" |
| Perspective Mode Mount Included | yes (adjustable angles) |
| Water detection transmit control | |
Networking & Connections |
|
| Garmin Marine Network Ports |
1 BlueNet (small connector) with GMN1 Adapter |
|---|---|
| Power connection | yes (2-wire) |
