Introducing the PRO 14 Inch Forecast unit, comes as a Plug And Play kit ready to link to your Garmin 1243/1223 units. (see below for compatible unit lists)
Specifications
Display Resolution - 1200x800
Weight - 8LBS
Waterproof - IP67
Mounting Options - Included gimbal
Touch screen
Dimensions 14.25" x 10"
Display Size 14.3" diagonal
Glass Type - Optical Bonding, with Anti-Glare UV coatings
Brightness - 1500 NITS (vivid sunlight readable)
Operational Temperature - -20c to +75C (-4F to +170F)
Touch Type - 10 Points Capacitive touch, Touch ON/OFF control
Remote OSD - Included remote control
Rugged Shock - 20G
Polarization Capable
Sonar Features and Compatibility
LIVESCOPE - All compatible units up to 2 Live scopes
SIDE VU / DOWN VU - All compatible XSV units or GCV box
Up to 6 Split screen boxes!
Cords/Cables
HDMI CABLE - 8 meters (26 feet)
DC POWER CABLE - 4 meters (13 feet)
USB CABLE - 8 meters (26 feet)
Electrical Features
POWER INPUT - 1 x DC 10V to 28V
TYPICAL CURRENT DRAW AT 12 VDC - 4.2 A
MAXIMUM CURRENT DRAW AT 12 VDC - 7A
Compatible Chart plotters
GARMIN 1243 (XSV) or NON - RECOMENDED UNIT 100% Functions
