NBT Lux Charger 12v/36v 20A 2 Bank AC-DC Onboard Charger

The NBT Lux Charger 12V/36V 2-Bank AC-DC On-Board Charger is a specialized, dual-voltage charging solution designed for modern marine electronics and trolling motor configurations. By combining two different voltage outputs into a single rugged unit, it provides a streamlined way to power your entire boat with professional-grade efficiency.

Key Features

• Dual-Voltage Output: Engineered with two dedicated, isolated banks to handle different power needs simultaneously:

  • Bank 1: A 12V output ideal for your cranking battery or DUAL Purpose Electronics  Battery.

  • Bank 2: A dedicated 36V output designed specifically for 36V trolling motor systems or a 36V lithium.

• 20A Fast Recovery: Delivers a total of 20A of charging power PER BANK, ensuring your high-capacity lithium batteries are topped off quickly between trips.

• LUX Lithium Optimized: Tuned with precision charging algorithms for LiFePO4 (Lithium Iron Phosphate) batteries, maximizing battery life and ensuring a safe, complete charge every time.

• Marine-Grade Construction: Features an IP67 waterproof rating, protecting the internal components from moisture, salt air, and the heavy vibrations common in tournament-style bass boats.

• Advanced Safety Features: Includes built-in protection against overcharging, short circuits, and reverse polarity, plus a "wake-up" feature for lithium batteries that have entered low-voltage protection mode.

Technical Specifications

• Outputs: 1 x 12V DC, 1 x 36V DC

• Total Charging Amps: 20A (Per Bank)

• Input Voltage: 100-240V AC

• Housing: Impact-resistant, fully encapsulated marine enclosure

• Best For: Anglers running a 36V trolling motor who want to charge their 12V starting or electronics battery from the same unit.
